Product details
Scanning mode: Electronic array
Channel:64
Probe element:192
Probe scan frequency/depth/radius:
convex probe:3.5/5Mhz,90/160/220/305mm，R60
trans-vaginal probe:6.5/8Mhz,40/60/80/100mm，R10
Display mode:
B, B/M, Color, PW, PDI
Applications:
Abdomen, Gynecology, Obstetric, Cardiac, Urology, Kidney, Lung
Measure:
B:Length,Area/Circumference,Angle,Trace,Distance
GA(CRL,BPD,GS,FL,HC,AC),EFW(BPD,FL)
B+M:Heart Rate.Time. Distance
B+PW:Velocity, Heart Rate(2), S/D, Depth
mage frame rate:24/s
Cineplay: 100/200/500/1000
Image save: jpg, avi, Mp4 and DlCOM format
Wifi type: 802.11g/20MHz/5G/450Mbps
Working system: Apple ioS and Android, Windows
Language: English,Russian,ltalian,Spanish,Chinese, Portuguese(Brazil)
Battery: built-in 4200mAh Lithium battery
Power:consumption 4W(probe run)/1.5W(probe stop)
Battery Replaceable: Yes
Battery last: 3 hours(working time), More than 5 hours(stand by time)
Battery charge:by wireless charge
Dimension:347x85x30mm
Probe head width:80mm
Weight: 304g
